Working condition and technical data
inlet air pressure 0.6-1.0MPa
inlet air temperature ≤60℃
the initial pressure drop ≤0.02MPa
outlet air dust particle size ≤0.1PPM-0.01PPM
* The above parameters pressure technical standard 0.7MPa
* Other special standard can be customized.
Product specifications
model |
Air capacity (Nm3/min) |
Air connection pipe diameter |
height (mm) |
Tube diameter (mm) |
weight (kg) |
SAGX-1 | 1.2 | G1" | 1054 | ф133 | 34 |
SAGX-2 | 2.5 | G1" | 1054 | ф133 | 34 |
SAGX-3 | 3.6 | G1" | 1066 | ф159 | 46 |
SAGX-4.5 | 4.8 | G1-1/2" | 1246 | ф159 | 52 |
SAGX-6 | 6.8 | G1-1/2" | 1246 | ф159 | 52 |
SAGX-8 | 8.5 | G2" | 1495 | ф219 | 74 |
SAGX-10 | 10.9 | G2" | 1495 | ф219 | 74 |
SAGX-12 | 12.8 | G2" | 1495 | ф219 | 74 |
SAGX-15 | 16 | DN65 | 1590 | ф219 | 90 |
SAGX-20 | 22 | DN65 | 1720 | ф219 | 95 |
SAGX-25 | 26.8 | DN80 | 1870 | ф219 | 101 |
SAGX-30 | 32 | DN80 | 1846 | ф273 | 152 |
SAGX-40 | 43.5 | DN100 | 2022 | ф325 | 189 |
SAGX-50 | 53 | DN100 | 2238 | ф412 | 255 |
SAGX-60 | 67 | DN125 | 2238 | ф412 | 259 |
SAGX-80 | 90 | DN125 | 2238 | ф412 | 260 |
SAGX-100 | 110 | DN150 | 2363 | ф462 | 309 |
SAGX-120 | 130 | DN150 | 2363 | ф462 | 310 |
SAGX-150 | 160 | DN200 | 2363 | ф462 | 323 |
SAGX-200 | 210 | DN200 | 2363 | ф462 | 326 |
SAGX-250 | 260 | DN250 | 2509 | ф512 | 419 |
SAGX-300 | 310 | DN250 | 2509 | ф566 | 521 |
